FEATURES Install Terminal Layout: Two-Sided Screw Mount / Wire Cover: Integrated Wire and Mounting Screw Terminals General Amplifier Type: Class-A/B Channel Design: 2/1 Channel Thermal Control: Thermal Management Control Power Supply: DC-DC PWM Power Supply Power Supply Design: MOSFET Power Current Protection: Over-Current, Over-Voltage and Thermal Protection Crossover: Variable Low-Pass / High-Pass Green/red Status LED 1 pair RCA pre-inputs 1 pair RCA pre-outputs SPECIFICATIONS Max Power Output Ratings Total Max Power: 300W RMS Power Ratings Per Channel into 4ohms (≤1%THD+N): 2 x 50W Per Channel into 2ohms (≤1%THD+N): 2 x 70W Bridged into 4ohms (≤1%THD+N): 1 x 130W Sound Tuning Crossover Frequency (Variable, OFF/LPF/HPF Selectable) 1/2 Ch: LP: 50Hz – 250Hz HP: 80Hz – 1.2kHz EQ (Equalizer): Bass EQ Fixed Frequency 45 Hz, Q=0.5, Variable Gain 0dB to +12dB Dimensions Footprint: 250 mm x 52 mm x 240 mm General Power Requirements: 14.4 V DC (11 V to 16 V) Input Sensitivity: 0.2 – 8.0 V Frequency Response: 5 Hz – 50 kHz (+ 0,-3 dB) Speaker Impedance: 4 or 2 Ω Signal to Noise: S/N Ratio (IHF A Weighted, Reference: rated power into 4ohms) 95 dB Weight: 1.9 Kg
